Coiling doors for homes and light commercial
Roll Up Garage Doors in Dallas-Fort Worth
Short answer
A roll up garage door, also called a coiling door, is built from interlocking horizontal slats that wind around a barrel above the opening instead of sliding back on ceiling tracks, which leaves the garage ceiling completely clear. Doors are quoted after a field measure, because size, layer count, insulation and hardware move the number significantly. Installations are completed in a single day.
When the Ceiling Is Spoken For, the Door Should Not Take It
Overview
A roll up garage door, also called a coiling door, is built from interlocking horizontal slats that wind around a barrel mounted above the opening rather than sliding back on ceiling tracks. It leaves the entire garage ceiling clear.
In Dallas-Fort Worth these show up in three places: light commercial bays and warehouses, alley-facing and detached garages in older Fort Worth and Dallas neighborhoods where headroom is tight, and home workshops where the owner wants the ceiling free for storage, lighting, a lift or a mezzanine. They are less common than sectional overhead doors on suburban tract homes, and that is the correct outcome, because on a standard attached garage a sectional door is usually the better product.
Professional Garage Concepts installs and services both. We have worked in DFW since 2001, hold 532 Google reviews at 4.8 stars, and maintain doors for commercial clients including Herzog and Coca-Cola. Call (817) 381-6173 and tell us what the space has to do.
How a Coiling Door Is Built
A roll up door has four main parts. The curtain is the door itself, made of interlocking galvanized steel slats that hinge against each other along their full length. The guides are the vertical channels on each jamb that the curtain rides in. The barrel is a steel tube above the opening holding the counterbalance springs inside it. The hood is the cover that encloses the coiled curtain.
Slat profile is the main spec. Flat and curved slat profiles are common on light-duty and residential coiling doors. Heavier commercial doors use thicker gauge slats and can add wind locks, which are end clips that keep the curtain in the guides under wind pressure. Insulated slats exist, built as a steel sandwich with a foam core, and they are worth asking about on any conditioned or west-facing DFW opening because a bare steel curtain radiates heat hard.
There is a second, cheaper category worth naming so you are not surprised by a quote. Roll up sheet doors use one continuous corrugated steel curtain rather than individual slats. They cost less and are common on self-storage and utility buildings. They are lighter duty, harder to repair section by section, and generally not what you want on a garage you use daily.
- Curtain of interlocking galvanized steel slats
- Vertical guides on each jamb, barrel and counterbalance springs above
- Hood encloses the coil and keeps weather off it
- Insulated slat options for conditioned or sun-exposed openings
- Wind locks available on heavier commercial curtains
Where a Roll Up Door Beats a Sectional
The advantage is entirely about what happens above and behind the opening. A sectional door needs horizontal track running back under the ceiling for roughly the height of the door plus 18 inches. A coiling door needs none of that. Everything lives in the barrel and hood directly above the opening.
That matters when the ceiling is doing something else. A workshop with overhead storage racks, a garage with a car lift, a bay with pipes, conduit, sprinklers or ductwork crossing the ceiling, or a shallow garage where the back wall is too close for horizontal track. It also matters where headroom above the opening is generous but backroom is not, which is a common shape in older detached and alley-loaded garages across Fort Worth and East Dallas.
Coiling doors are also built for cycle volume. Commercial coiling doors are engineered for far more daily openings than a residential sectional, which is why they dominate loading bays, service shops and fleet garages. On a busy shop, that difference shows up as fewer service calls.
What they give up: styling and insulation. A coiling door will never look like a carriage house door, and its insulation options are more limited. On a front-facing suburban garage, a sectional door is nearly always the right answer.
- No horizontal ceiling track, so the ceiling stays fully usable
- Works in shallow garages where backroom is short
- Built for higher cycle counts in commercial and shop use
- Compact stack: the whole door lives in the barrel above the opening
- Trade-off: fewer style options and more limited insulation than sectional
Headroom, Clearances and What We Measure
Roll up doors trade one clearance requirement for another. They need essentially no backroom, but they do need vertical space above the opening for the coil, and the taller the door the larger the coil diameter. On a residential opening that is often a foot or more of clear wall above the header, and it has to be clear of lights, conduit and duct runs.
They also need solid structure at the jambs and header, because the guides and barrel brackets carry the whole door load into that framing. On masonry and steel-framed commercial openings this is straightforward. On a wood-framed residential garage we look carefully at the header before committing to a coiling door.
Two more North Texas notes. Sun exposure on a bare steel curtain is real, so ask about insulated slats and a light color on any west-facing opening. And a coiling door still needs the same annual attention a sectional does: the guides stay clean and lubricated, the counterbalance inside the barrel gets checked for correct tension, and the bottom bar seal gets inspected where it meets a slab that has probably moved since the building went up.
- Vertical clearance above the header for the coil, more on taller doors
- Effectively no backroom requirement
- Solid header and jamb structure to carry the barrel and guide loads
- Insulated slats and lighter colors for west-facing DFW openings
- Annual service: guide cleaning, counterbalance tension, bottom seal check
Straight pricing
Roll Up Door Pricing in DFW
Coiling doors are priced per opening after a field measure, because slat gauge, curtain width, coil size and structure all change the number. These bands are what comparable DFW door jobs run.
Light-duty residential coiling door
$2,000 to $5,000installed
Detached, alley-loaded and workshop garages with tight backroom
- Interlocking galvanized steel slat curtain
- Guides, barrel, counterbalance springs and hood
- Bottom bar and seal fitted to the slab
- Old door removed and hauled away
Insulated or wider residential curtain
$4,000 to $9,000installed
Conditioned shops, west-facing openings and wider bays
- Insulated slats with a foam core
- Heavier gauge curtain for wider openings
- Lighter finish colors for sun exposure
- Motor operator sized to the curtain
Light commercial coiling door
Quoted per openingafter field measure
Service bays, shops, warehouses and fleet garages
- Commercial gauge slats and guides
- Wind lock options where required
- High cycle counts and motor operators
- Preventive maintenance available on the same account
Answers
Frequently asked questions
Still stuck? Call (817) 381-6173 and talk to someone who does this every day.
What is a roll up garage door?
A roll up garage door, also called a coiling door, is built from interlocking steel slats that wind around a barrel mounted above the opening instead of running back on ceiling tracks. It leaves the entire garage ceiling clear, which is why it is common in workshops, alley garages and light commercial bays.
Are roll up doors better than sectional garage doors?
Neither is better overall. A roll up door wins when the ceiling or the backroom is needed for something else, such as a car lift, storage racks, ductwork or a shallow garage, while a sectional overhead door wins on a standard attached suburban garage because it offers far more styling and better insulation.
Can you install a roll up door on a house?
Yes, roll up doors work well on detached, alley-loaded and workshop garages, which are common in older Fort Worth and Dallas neighborhoods. They need vertical clearance above the header for the coil and solid framing to carry the barrel and guide loads, both of which we verify before quoting anything.
Do roll up garage doors need less headroom?
They need almost no backroom, which is the real advantage, but they do need vertical space above the header for the coil, often a foot or more depending on door height. A sectional door reverses that: less space above the opening, but horizontal track running back under the ceiling for the door height plus about 18 inches.
Can a roll up door be insulated?
Yes, insulated slats are built as a steel sandwich with a foam core, and they are worth specifying on any conditioned space or west-facing opening in North Texas, where a bare steel curtain absorbs afternoon sun and radiates it inward. Insulation options are still more limited than on sectional doors.
What is the difference between a roll up sheet door and a coiling slat door?
A sheet door uses one continuous corrugated steel curtain and costs less, which is why it is standard on self-storage buildings, while a coiling slat door uses individual interlocking slats, is heavier duty, and handles far more cycles. A slat door can also be repaired slat by slat instead of replacing the whole curtain.
