Steel doors built for North Texas
Metal Garage Doors in Dallas-Fort Worth
Short answer
Metal garage doors, meaning steel, are roughly 85 percent of what gets installed on Dallas-Fort Worth homes, because steel holds its shape in 120F garage heat, takes a baked-on finish that survives Texas UV and accepts insulation cores. Doors are quoted after a field measure, because size, layer count, insulation and hardware move the number significantly. Installations are completed in a single day.
Every Steel Door Looks the Same in a Photo. The Spec Sheet Is Where They Separate.
Overview
Metal garage doors, meaning steel doors, are roughly 85 percent of what gets installed on DFW homes, and for good reason. Steel holds its shape in 120F garage heat, takes a baked-on finish that survives Texas UV, accepts insulation cores, and is available at every price point from a $2,000 single to a $10,000 insulated carriage house.
The catch is that steel doors are sold on looks and built on numbers. Two doors that appear identical from the street can differ by a full gauge of steel and two layers of construction, which is the difference between a door that shrugs off a basketball and one that dents when a kid leans a bike against it.
Professional Garage Concepts has installed steel doors across the Metroplex since 2001, and we carry 532 Google reviews at 4.8 stars. You can press on a 24 gauge panel and a 25 gauge panel side by side in our Keller and Grand Prairie showrooms, which takes about four seconds and settles the question permanently.
Steel Gauge: 24 vs 25 vs 26
Gauge measures steel thickness, and the scale runs backward. Lower numbers are thicker. A 24 gauge skin is thicker and stiffer than 25 gauge, which is thicker than 26 gauge. That is the entire rule, and it is the first number to ask any contractor for.
Most builder-grade doors on DFW tract homes are 25 or 26 gauge single-layer steel. They are inexpensive and they dent. A basketball, a bike handlebar, a backing trailer hitch or a hail event will leave a mark you cannot undo, because a dent in a single steel skin has nothing behind it to push against.
Stepping to 24 gauge costs real money and it buys real stiffness. On a wide 16 or 18-foot double door it matters more than on a single, because a wider panel flexes more across its span. If your door faces the street, gets used daily, or has kids and sports equipment near it, 24 gauge is the spend that keeps paying.
- Lower gauge number means thicker steel: 24 is thicker than 25, 25 is thicker than 26
- 26 and 25 gauge: builder grade, lowest cost, dents easily
- 24 gauge: noticeably stiffer, better hail and impact performance
- Gauge matters more on wide double doors than on singles
- Always ask for the gauge in writing, not just the model name
Single, Double and Triple Layer Construction
Layer count changes more about a steel door than gauge does. Single layer is one steel skin and nothing behind it. It has no meaningful insulation value, it is the loudest door to operate, and it is the easiest to dent because the skin is unsupported.
Double layer, sometimes called two-layer, adds an insulation core bonded behind the steel skin, typically polystyrene board in the R-6 to R-9 range. The foam supports the skin, so the door is stiffer and quieter as well as warmer. This is the value sweet spot for most DFW garages.
Triple layer sandwiches the insulation between a front steel skin and a back steel skin. That back skin does three things: it roughly doubles panel rigidity, it protects the insulation from being gouged by bikes and ladders, and it gives you a finished interior instead of exposed foam. Combined with an injected polyurethane core, a triple-layer door reaches roughly R-12 to R-18, runs noticeably quieter, and resists dents far better than anything below it.
For an attached North Texas garage, especially one holding a water heater or sitting under a bedroom, triple layer with polyurethane is the construction worth stretching for. Insulation upgrades add $500 to $1,000 for polystyrene and $1,000 or more for polyurethane.
- Single layer: one skin, no insulation, loudest, dents easily
- Double layer: polystyrene core, roughly R-6 to R-9, quieter and stiffer
- Triple layer: steel back skin, roughly R-12 to R-18 with polyurethane, best dent resistance
- Back skin also protects the core from garage damage and finishes the interior
- Polyurethane bonds to both skins, which is what kills the hollow drum sound
Wind Ratings and Dent Resistance in a Hail Market
North Texas sits in a severe convective wind and hail corridor. A spring squall line producing 70 to 80 mph straight-line gusts is a normal Metroplex event, not an outlier. The garage door is the largest opening in the house and the most common structural failure point when that pressure hits.
Wind-rated steel doors are engineered systems, not just thicker panels. They add reinforcing struts across every section, heavier end hinges and rollers, a stronger track, and additional jamb anchoring into structural framing. Manufacturers publish a design pressure rating for each door in each width, because a 16-foot double door carries far more load than an 8-foot single. Check your city and HOA requirements, because wind-load rules in Texas are set locally and vary across DFW.
The same construction helps with hail. A strutted, triple-layer 24 gauge panel flexes less under impact than an unsupported 26 gauge skin, and less flex means fewer visible dents and less cracking of the paint film. Once the paint film cracks, moisture reaches the steel and the door starts working on its own failure.
- Reinforcing struts on every section, not just the top
- Heavier hinges, rollers and track to carry the load
- Extra jamb anchoring into structural framing
- Design pressure ratings quoted for your exact door width
- Stiffer panels dent less and crack the paint film less in hail
Finish Durability at 100F and Above
A steel garage door in DFW faces a full afternoon of direct sun and surface temperatures well past 140F on a dark color. The finish is what stands between the steel and that.
Quality steel doors use hot-dipped galvanized steel with a multi-layer factory finish: a bonding primer, then a baked-on polyester or similar topcoat. Baked-on factory finishes hold color and gloss under Texas UV far longer than a field-applied paint job. Dark colors, especially black and deep bronze, absorb the most heat and are the most likely to show fade over a decade, which is worth knowing before you pick black to match the window frames.
Maintenance is genuinely light. Wash the door twice a year with mild soap and water to clear the chalky film and the driveway grit that holds moisture against the finish. Check the bottom section for rust starting at the edges, because the bottom is where splash-back and slab heat do their work. If the finish is chipped down to bare steel, touch it up rather than waiting, because rust perforation at the bottom section is one of the few conditions that make a steel door unrepairable.
- Hot-dipped galvanized steel with baked-on factory topcoat
- Dark colors absorb the most heat and fade first
- Wash twice a year with mild soap and water
- Inspect the bottom section for rust at the edges every spring
- Touch up chips to bare steel before they perforate
Straight pricing
Metal Garage Door Pricing in DFW
These are typical DFW installed ranges rather than a quote, and door size, gauge, layer count and wind rating all move the number. You get a written price before anything is ordered.
Single-layer steel
$2,000 to $3,500installed
Detached garages, rentals, and straightforward like-for-like replacements
- 25 or 26 gauge steel skin
- Baked-on factory finish
- New track, rollers, hinges and correctly sized springs
- Old door hauled away
Two-layer insulated steel
$3,500 to $6,000installed
Most attached DFW garages, the market's most common choice
- Polystyrene core, roughly R-6 to R-9
- 24 or 25 gauge exterior skin
- Quieter operation than single layer
- Optional window sections and carriage styling
Three-layer polyurethane, wind-rated available
$6,000 to $10,000installed
Attached garages under living space, wide double openings, hail exposure
- 24 gauge front and back steel skins
- Injected polyurethane core, roughly R-12 to R-18
- Reinforcing struts on every section
- Wind-load rated configurations available
Answers
Frequently asked questions
Still stuck? Call (817) 381-6173 and talk to someone who does this every day.
What steel gauge should a garage door be?
For a DFW home, 24 gauge steel is the practical standard when dent resistance matters, because gauge runs backward and 24 is thicker than 25 or 26. Builder-grade doors are usually 25 or 26 gauge single layer, which dents from a basketball or a bike. Gauge matters most on wide 16 and 18-foot double doors.
What is the difference between single, double and triple layer garage doors?
Single layer is one steel skin with no insulation, double layer adds a polystyrene core behind the skin for roughly R-6 to R-9, and triple layer sandwiches insulation between front and back steel skins, reaching roughly R-12 to R-18 with polyurethane. Triple layer is the stiffest, quietest and most dent resistant.
Do metal garage doors dent easily?
Single-layer 25 and 26 gauge steel doors dent easily because the skin has nothing behind it, while a 24 gauge triple-layer door with reinforcing struts resists impact far better, since the insulation core and back skin support the face. Dent resistance is set by gauge, layer count and strutting, not by brand.
Do I need a wind-rated garage door in North Texas?
Check your city code and HOA first, because wind-load requirements in Texas are adopted locally and vary across the Metroplex, and a home built to a wind-load spec generally needs a replacement that meets it. Wind-rated construction is worth considering regardless, since spring storm lines here produce 70 to 80 mph gusts.
Will a steel garage door fade in Texas sun?
A quality steel door uses hot-dipped galvanized steel with a baked-on factory topcoat that holds color under Texas UV for many years, though dark colors such as black and deep bronze absorb the most heat and show fade soonest. Washing the door twice a year with mild soap and water extends finish life.
How much does a metal garage door cost in DFW?
Metal garage doors in Dallas-Fort Worth run roughly $2,000 to $3,500 installed for single-layer steel, $3,500 to $6,000 for two-layer insulated, and $6,000 to $10,000 for three-layer polyurethane construction with wind-rated options. Size, gauge, glass and hardware move the number, and removal of the old door is included.
